Tapered masking plugs for pipes, shafts, holes and internal threads.
Shore A
50-60
Temp. Range
-90°C ~ 315°C
Post Cure
Yes
Chemical Res.
Yes
Acid Res.
Yes
Technical information and usage areas
All our products are manufactured in our facility with special recipes and quality certifications (ISO 9001:2015, RoHS, REACH).
Tapered plugs are designed in a conical shape to fit pipes, shafts, holes and internal threads. Tapered plugs offer the advantage of single product use at close diameters. They are masking plugs with high heat and acid resistance.
Tapered plugs are made from silicone compound and come in different sizes. They are among the most commonly used masking plugs. Thanks to its tapered structure going from small diameter to large diameter, it allows the same product to be used in several areas.
Material: Manufactured in our factory with our own formula silicone compounds and special activators in varying hardness (50-80 ShoreA) depending on diameters.
Post Cure: After production, it is subjected to final curing (postcure) process for 4 hours in our special ovens.
58 variants available
| SKU | d1 (mm) | d2 (mm) | L (mm) | Ø | UNF | Shore A | Qty/Pack |
|---|---|---|---|---|---|---|---|
| SMT 79 | 0.51 | 1.98 | 19.05 | M2 | - | 60 | 1000 |
| SMT 79 XL | 0.51 | 1.98 | 25.4 | M2 | - | 60 | 1000 |
| SMT 99 | 0.81 | 2.54 | 15.88 | - | - | 60 | 1000 |
| SMT 99 XL | 0.81 | 2.54 | 25.4 | - | - | 60 | 1000 |
| SMT 99 XXL | 0.79 | 3.18 | 15.88 | M3 | - | 60 | 1000 |
| SMT 100 | 1.19 | 5 | 27.9 | M4 | - | 55 | 1000 |
| SMT 100 XL | 1.19 | 4.78 | 55.6 | M4 | - | 55 | 1000 |
| SMT 101 XL | 1.19 | 5.49 | 38.1 | M3, M4, M5 | - | 55 | 1000 |
| SMT 101 | 1.6 | 5.08 | 19.05 | - | - | 55 | 1000 |
| SMT 307 | 3 | 7 | 25 | M4, M5 | - | 55 | 1000 |
| SMT 102 | 3.18 | 6.35 | 19.05 | M5, M6 | .1/4" | 55 | 1000 |
| SMT 102 XL | 3.18 | 6.35 | 25.4 | M5, M6 | .1/4" | 55 | 1000 |
| SMT 310 | 3.18 | 9.53 | 31.75 | M8 | .5/8" | 50 | 1000 |
| SMT 312 | 3.2 | 12.7 | 50.8 | M10 | .3/8" | 50 | 500 |
| SMT 103 | 4.78 | 8.71 | 15.88 | M7, M8 | .5/8" | 50 | 1000 |
| SMT 103 XL | 4.78 | 8.71 | 25.4 | M7, M8 | .5/8" | 50 | 500 |
| SMT 510 | 5 | 10 | 25 | M6, M7, M8 | - | 50 | 1000 |
| SMT 510 XL | 5 | 10 | 48 | M6, M7, M8 | - | 50 | 500 |
| SMT 104 XL | 6.35 | 11.1 | 25.4 | M10 | .3/8" | 50 | 250 |
| SMT 000 XL | 7.9 | 12.7 | 25.4 | M10 | .3/8" | 50 | 250 |
| SMT 106 XXL | 7.95 | 14.27 | 28.58 | M10, M12, M14 | .7/16", .1/2", .9/16" | 50 | 250 |
| SMT 106 XL | 8.99 | 13 | 25 | - | - | 50 | 250 |
| SMT 107 | 9.53 | 14.3 | 25.4 | M10, M12, M14 | .7/16", .1/2", .9/16" | 50 | 250 |
| SMT 00 | 10.31 | 15.09 | 25.4 | - | - | 50 | 250 |
| SMT 0 XL | 11.13 | 17.45 | 25.4 | M14, M16, M18 | .5/8" | 50 | 250 |
| SMT 0 | 12.7 | 16.66 | 25.4 | M16 | .5/8" | 50 | 250 |
| SMT 0 XXL | 13 | 17 | 25.4 | - | - | 50 | 100 |
| SMT 1 | 14.27 | 19 | 25.4 | M18, M20 | .3/4" | 50 | 100 |
| SMT 2 | 15.88 | 19.99 | 25.4 | M20 | .3/4" | 50 | 100 |
| SMT 2,5 | 16 | 21.01 | 25.4 | - | - | 50 | 100 |
| SMT 3 | 18.26 | 23.83 | 25.4 | M22 | .7/8" | 50 | 100 |
| SMT 3,5 | 18.01 | 24.03 | 30 | M22 | 7/8" | 50 | 100 |
| SMT 4 | 19.99 | 26.01 | 25.4 | M22, M24 | 1." | 50 | 100 |
| SMT 4,5 | 19.05 | 27.99 | 50.8 | M30 | 1.1/4" | 50 | 100 |
| SMT 5 | 23.01 | 27 | 25.4 | M27 | - | 50 | 100 |
| SMT 5,5 | 24.99 | 30.99 | 30 | - | - | 50 | 100 |
| SMT 6 | 26.19 | 31.75 | 25.4 | M33 | 1.1/4" | 50 | 100 |
| SMT 6,5 | 27 | 33.99 | 25.4 | M33 | 1.1/4", 1.3/8" | 50 | 100 |
| SMT 7 | 30.18 | 36.53 | 25.4 | M36 | 1.3/8" | 50 | 100 |
| SMT 7,5 | 31.75 | 38.89 | 25.4 | M39 | 1.1/2" | 50 | 100 |
| SMT 8 | 33.35 | 41.28 | 25.4 | M39, M42 | 1.1/2" | 50 | 50 |
| SMT 8,5 | 35.71 | 42.88 | 25.4 | M42 | - | 50 | 50 |
| SMT 8,5 XL | 36 | 43.99 | 40.01 | M42, M45 | - | 50 | 50 |
| SMT 9 | 37.31 | 44.45 | 25.4 | M48 | - | 50 | 50 |
| SMT 9,5 | 38.1 | 46.05 | 25.4 | - | - | 50 | 50 |
| SMT 9,5 XL | 41 | 49 | 40 | - | - | 50 | 50 |
| SMT 10 | 41.28 | 50 | 25.4 | - | - | 50 | 50 |
| SMT 10,5 | 44.45 | 52.4 | 25.4 | M56 | - | 50 | 50 |
| SMT 10,5 XL | 46.99 | 54.99 | 40.01 | - | - | 50 | 25 |
| SMT 11 | 47.63 | 55.96 | 25.4 | M56 | - | 50 | 25 |
| SMT 11,5 | 50.01 | 62.71 | 25.4 | - | - | 50 | 25 |
| SMT 11,5 XL | 50 | 60 | 45 | - | - | 50 | 25 |
| SMT 12 | 53.98 | 63.5 | 25.4 | M64 | - | 50 | 25 |
| SMT 13 | 57.94 | 68.28 | 25.4 | - | - | 50 | 10 |
| SMT 13,5 | 61.93 | 75.01 | 34.93 | - | - | 50 | 10 |
| SMT 14 | 76.2 | 88.9 | 38.1 | - | - | 50 | 10 |
| SMT 15 | 82.55 | 101.6 | 38.1 | - | - | 50 | 10 |
| SMT 16 | 88.9 | 127 | 50.8 | - | - | 50 | 10 |
